Connecting Your JTX Machine to Kinomap
Written by: Caitlin O'Brien
Date Published: March 03, 2026
Updated on: June 05, 2026
How To Install Kinomap
Connecting Kinomap to your JTX Fitness equipment is easy and you should only need to do it once. Just follow the steps below.
- Ensure Bluetooth is enabled on your mobile device.
- Download and install the Kinomap app from your App Store or Google Play Store.
- Launch the Kinomap app.
- Select the Menu Button (three horizontal bars) on the top right-hand corner.
- Select My Profile then Settings then Equipment Management.
- Select “My Equipment” from the options available.
- Press the “+” symbol on the top left to continue.
- Select the machine type (Treadmill, Exercise Bike, Elliptical, Rowing machine).
Don’t follow these instructions if you have the 2025 Zenith Rise. Just open the app on your machine and it will automatically connect.
Connecting Your JTX Treadmill
- Select Treadmill.
- From the list of brands, select JTX Fitness then press Next. RunRise users should select FTMS.
- Under Found Equipment select the equipment that begins with “iConsole”. RunRise users should select the equipment that begins FS-.
- When prompted to Run, start the treadmill and begin running.
- Once you see your activity being recorded, press Next.
- From the My Equipment page you can return to the Home Screen and begin.
Connecting Your JTX Rowing Machine
- Select Rowing Machine.
- From the list of brands, select FTMS then press Next.
- Under Found Equipment select the equipment that begins with DFIT.
- In the pop-up box, you'll be asked to enter the brand and model. Enter JTX in both fields.
- Start rowing. You should see your activity being recorded. Then press Next.
- From the My Equipment page you can return to the Home Screen and begin.
Connecting Your JTX Exercise Bike
- Select Exercise Bike.
- From the list of brands, select JTX Fitness then press Next. Studio Pro and Racer-M users should select FTMS.
- Under Found Equipment select the equipment that begins with “iConsole”. Studio Pro and Racer-M users should select the equipment that begins FS-.
- When prompted to Ride, start pedalling.
- Once you see your activity being recorded, press Next.
- From the My Equipment page you can return to the Home Screen and begin.
Connecting Your JTX Cross Trainer
Tri-fit
- Select Elliptical.
- From the list of brands, select JTX Fitness then press Next.
- Under Found Equipment select the equipment that begins with “FAD” or “iConsole”.
- When prompted to Run, start using your cross-trainer.
- Once you see your activity being recorded, press Next.
- From the My Equipment page you can return to the Home Screen and begin.
Strider-X8
- Select Exercise Bike.
- From the list of brands, select iConsole then press Next.
- Select iConsole Bike then press NEXT.
- Select your machine then press ADD.
- When prompted to Pedal, start using your cross-trainer.
- Once you see your activity being recorded, press NEXT.
- From the My Equipment page you can return to the Home Screen and begin.
Pace-F6
- Select Exercise Bike.
- From the list of brands, select iConsole or Sensors then press Next.
- Select the Bluetooth device “IBIKING 10 LEVELS” or “LEVEL EXERCISE BIKE” and press Next.
- Select your machine from the list.
- In the pop-up box, you'll be asked to enter the brand and model. Enter JTX in both fields.
- When prompted to Pedal, start using your cross-trainer.
- Once you see your activity being recorded, press Next.
- From the My Equipment page you can return to the Home Screen and begin.
